TravelMaster™ 115 | Inclined autowalk – KONE

Description

The KONE TravelMaster™ 115 inclined moving walk is designed for use in commercial buildings. These can include large grocery stores, department stores, shopping malls and exhibition centers. It is also suitable for airports and railway stations. It complies with all relevant international and local safety codes.

Specifications

  • Operational environment: indoor, semi-outdoor
  • Speed: 0.5 m/s
  • Inclination: 10º, 12º
  • Pallet width: 1000 mm
  • Vertical rise: up to 7 m
Inclined_autowalk_Dusseldorf_Airport_ICE_BC:720x720%281-1%29

Tools and downloads

Escalator Planner

Escalator Planner helps you select the right product as well as create detailed specifications, BIM equipment models and CAD drawings for preliminary planning.

KONE TravelMaster™ 115 brochure

Product information in a nutshell for the KONE TravelMaster™ 115

KONE Escalator DX

Differentiate with a redefined user experience - increase the attractiveness of your building with KONE Escalator Digital Experience offering.

Inclined autowalk options and highlights

Travelmaster 115

Inclined autowalk energy-efficiency

Energy-efficient people flow that keep your building moving:

  • Smart operational modes and inverter optimize inclined escalator energy consumption under different load conditions
  • Long lasting LED lighting is up to 80% more efficient than fluorescent lighting and lasts up to 10 times longer
  • An energy efficient inverter provides smooth speed regulation during standby operation and minimizes energy consumption at full speed
  • The optional regenerative technology cuts power consumption by recycling energy and feeding it back into the system
Travelmaster 115

Escalator safety

Peace of mind with the latest safety technology:

  • High (1100 mm)balustrade improves escalator safety with a multiple level inclined escalator layout
  • The pallet loose monitor and Sprialock threaded screw increase escalator safety for passengers and reliability on our pallets
  • New traffic signalization solutions to provide extra guidance
  • Fall-prevention barrier and extended balustrades provide additional passenger protection
  • Extensive monitoring options such as KONE Remote Monitoring™ and KONE E-link™ to integrate with your building management systems
Travelmaster 115

Inclined autowalk design

Proven, reliable inclined escalator design to provide safe people flow and maximum availability in environments with medium to high traffic:

  • Reduced escalator dimensions frees up more space for commercial activities
  • Real inclinations allows for better inclined autowalk alignment and enhanced visual appearance of the building
  • Flexible intermediate support placement allows easier integration with the building
  • Innovative and attractive inclined autowalk lighting solutions that also improve passenger guidance and escalator safety
  • A wide range of inclined escalator design options to create stunning visual effects and perfectly match your building’s architecture
  • High quality component finishes and a harmonized look and feel throughout the KONE product portfolio

Contact us for a detailed cost estimate

Related topics

Escalator and autowalk solutions

Product name
Type
Segment
Maximum rise
Speed
Inclination
24/7 Connected Services available
Energy-efficiency class
TravelMaster 110
EscalatorCommercial, retail, hotel, office, multi-use, stadium, medical
13 m
0.5 m/s30°, 35°
YesA+++
TravelMaster 115
Inclined autowalkCommercial, retail, hotel, office, multi-use, stadium, medical
7 m
0.5 m/s
10°, 12°
Yes
A+++
TransitMaster 120
EscalatorInfrastructure
15 m
0.5, 0.65, 0.75 m/s27.3°, 30°, 35°Yes
A+++
TransitMaster 140
EscalatorInfrastructure
35 m
0.5, 0.65, 0.75 m/s27.3°, 30°YesA+++
TransitMaster 165
Horizontal autowalkInfrastructure
100 m length
0.5, 0.65, 0.75 m/s
0-6°
YesA+++

Further information about KONE premium escalators with TransVario drive (TravelMaster 110T, TransitMaster 120T, TransitMaster 140T) available here.
